AJA Kona 5 multiple outputs

DigitalVTDigitalVT
in MAIN

Anybody had any luck with getting synchronised multiple 12G outputs on a AJA Kona 5?


Am using a Sonnet TB3 enclosure run from a M4 Max MBP. And even with two 12G outputs they’re not synchronised?

Had considered purchasing the new Sonnet TB5 enclosure when it’s out, but not yet convinced this will produce the synchronised outputs?


Thoughts?

Comments

  • MilluminMillumin

    Hello @DigitalVT,

    Millumin does not support AJA Kona 5 multiple-output synchronization feature. We have planned to work again on this device later 2025 or early 2026.

    The new Sonnet TB5 (not out yet) will make you able to output 4 x 2160p60 with the TB5 bandwidth (TB3/4 bandwidth limits to 4 x 2160p30). But it will not help to synchronize.

    Right now, you can use a Decklink 8K Pro to output to 4 x 2160p frame-sync. See this article.

    Best. Philippe

  • DigitalVTDigitalVT

    Thanks Phillipe,

    Thought the AJA box would be better than the Black Magic. But thanks! Will look into the Decklink!

    Ian
